In addition, there are two Loopback inputs - these are virtual software inputs, that allow you to route system audio (or anything else) and have them show up in your DAW - making it possible to record say the output of your web browser into your DAW via these Loopback inputs. Essentially you have up to 6 separate mixes with access to all inputs and DAW returns which can be balanced as required and output to any of the available outputs. The Saffire MixControl application is where all the clever stuff happens, as well as all the regular settings (clock, samplerate ADAT mode etc) you have access to full monitor and routing options. I was also able to set the minimum latency within Live without any stuttering and good stability.
SAFFIRE MIXCONTROL METERS DRIVERS
As far as stability goes, I tested this on OX S with Ableton Live 8 and Logic Pro as well as various other software which outputs and inputs audio, including SoundFlower drivers and didnt find any problems.
SAFFIRE MIXCONTROL METERS MAC OS X
It is not possible to operate the Saffire Pro24 without installing the drivers and control panel, but there are drivers for both Windows XP and Vista (64-bit too) plus Mac OS X 10.4.11 and above. Speaking of gain, the headphone outs have plenty, should you need it - something that can be overlooked, making live work without a mixer almost impossible as you can hear anything over the audio in the room. The line inputs have switchable sensitivity for -10dB and +4dB operation - switchable in software. Actually, they DO sound good and are quiet, even at full gain - I used then on dynamic and condenser mics and was please with the results.
MIDI in and out and S-Pdif finish things off.įirst up, the mic amps are of the Focusrite Award Winning variety which, as they say in their own blurb are best in class. It's a 1/2 rack, 1 unit high device with two, combi instrument/Mic connectors, each with dedicated level control, 48v global switching, a five segment, four channel LED meter, dedicated monitor level (affects outputs 1&2) and Headphone out with separate level control (outputs 3&4) on the front panel.Īround the back, are line inputs 3&4, analog outs 1-6, an ADAT (or optical) input which provides either 8 ch at 44.1kHz/48kHz or 4 at 88.1kHz/96kHz via SMUX. The Saffire Pro24 is a 16 in, 8 out Firewire Audio interface capable of up 96kHz operation.
When we first saw this at the Lims Show earlier in the year, my interest was piqued - I've been looking for a new sound IO for my studio system here - especially something with on board mixing and routing, in my own head, I was thinking maybe I can retire the little mixing desk I have and work totally in the inferface.
